3 Innovative International Projects To Reconcile The Underground And The Surface


Oct 15, 2018 - one month ago

By Supply Post

Finalists for the Innovative Use of Underground Space category

ITA Tunnelling Awards 2018

Since 2015, the international competition "the ITA Tunnelling Awards" seeks and rewards the most ground-breaking innovation and outstanding projects in tunnelling and underground space utilization.

The 2018 edition will take place on 7 November, in Chuzhou-Nanjing during the 20th Chinese Tunnel and Underground works Conference (CTUC - from 5 to 6 Nov). This will be followed by technical visits on Nov 8 in Nanjing, Chuzhou and Shanghai.

In 2018, the 3 finalists for the award of “Innovative Use of Underground Space” all have one common trend: they build bridges. Bridges from the past to the present, bridges between urban activities and nature, bridges between the underground and the surface.

The Innovative Use of Underground Space category highlights the most unexpected and accomplished projects constructed underground. These projects aim to develop both ecological aspects as well as efficient urban planning, by shrinking the gap between the surface and the underground: creating new pedestrian connections, developing new utilizations of subterranean spaces and transferring surface functions to the ground.

The 3 finalists:

1. ECOLOGICAL CIVILIZATION CONSTRUCTION AND INTENSIVE LAND USE OF METRO PROJECT:

With the rapid development of tertiary industry in China since the 1980’s, the roles of cities have gradually been transformed into distribution and service centres. But land is a non-renewable and extensive use of urban space, leading to unequal repartition of services and functions.

Intensive land use, on the contrary, is based on the selection of modes appropriate to their different intrinsic attributes. Intensive use of land generally follows three trends: Land Construction, Buildings and Traffic.

Located in  Tanglangshan  Park  Shenyun, the project in an abandoned quarry comprises of a  “Shenyun Vehicle Section” which is at the north of  Longwan  Road in  Nanshan  District,  and at the east side of  Nanping  Express  Highway.  The site is approximately 307 meters wide and 905m long, with floor space of 31.85ha  and an overall floorage of 168,000.

Based on the purpose of intensive land use, Shenyun  Vehicle  Section combines and considers both ecological construction and business development requirements. The vehicle section mixes rail traffic, sports facilities, public facilities and a scientific research and education base.  Natural and urban space are equally integrated within the project. This site is a wonderful reflection of the harmonious co-existence between human activities and nature, creating an ecological connection between hills and contributing to the natural balance of the area.

2. UNDERGROUND PEDESTRIAN PASSAGE IN TIANJIN

The project consists of the construction of an underground pedestrian walkway in Tianjin, in New Badalei area. It aims to connect the north and south concourses of the Heiniucheng Road freeway and the Neijiang North Road.

The underground walkway beneath Heiniucheng Road has a length of 92,6m. The tunnel was constructed with an earth pressure balance pipe jacking machine. With a size of 10,4m x 7,55m, the pipe sections used in the underground walkway are the largest in the world.

Heiniucheng Road is one of the most important roads in Tianjin with a width of 66,5m. It is the first time the super-large cross-section rectangular pipe-jacking tunnelling method was used in the watery and weak strata in Tianjin.

3.

THE NORWEGIAN ROCK BLASTING MUSEUM: THE ONLY UNDERGROUND MUSEUM IN THE WORLD

The Norwegian Rock Blasting Museum is an underground museum located near the Olympic City of Lillehammer in Norway.

The museum was created 25 years ago by the main stakeholders of the industry, to recognise Norway’s close and extensive history with tunnels.

The Norwegian Rock Blasting Museum is an entertaining and informative journey through the history of Norwegian tunnelling and rock blasting, with a 240 m long semi-circular tunnel as the main attraction. The tunnel display equipment and tunnelling techniques date from the beginnings of tunnelling all the way to modern computerised drilling and TBM boring.  This is a unique museum, and possibly the only purpose-built "tunnelling museum" in the world.
