Finlay Introduces C-1550+ Tracked Cone Crusher

Feb 21, 2025 - 6 months ago

Finlay is setting a new standard for high-capacity production in the surface ore mining and aggregate industries with the C-1550+ tracked cone crusher.

Finlay Introduces C-1550+ Tracked Cone Crusher
Building on the strengths of its predecessor (the C-1550), the C-1550+ offers increased performance, enhanced efficiency, and improved serviceability.

At the core of the C-1550+ is the upgraded Terex 1300X cone crusher, which features a 1300mm (52”) head diameter. Engineered for durability and intelligent design, this crusher delivers a 15% increase in tonnage and production compared to the C-1550. This improvement is achieved through higher clamp forces and a longer throw, resulting in greater profitability for owners, operators, and contractors. Additionally, the C-1550+ offers improved transportability, thanks to its lighter weight.

Performance is enhanced further with ultrasonic level sensors that regulate the material flow from the hopper to the crushing chamber. This ensures consistent and efficient crushing, while the machine’s ability to accept an all-in feed eliminates the need for additional screening equipment.

Finlay Introduces C-1550+ Tracked Cone Crusher
Other features that enhance the high-capacity production capabilities of the C-1550+ include full hydraulic closed side setting (CSS) adjustment with electronic monitoring for precise control, as well as a fuel-efficient direct drive transmission through a wet clutch to maximize fuel efficiency and reduce operating costs. The large hopper/feeder is equipped with an automatic reset hydraulic tramp relief system that protects the chamber and minimizes downtime if uncrushable material enters the chamber. This system minimizes downtime by automatically removing contaminants via the purge chute, enabling smoother operations.

Finlay Introduces C-1550+ Tracked Cone Crusher
The C-1550+ is also designed with safety and maintenance efficiency in mind. Its mechanically designed liner retention and common upper frame make it compatible with all liner configurations, including coarse, medium, and fine. This feature simplifies liner changes and maintenance, maximizing operational uptime. Generously sized catwalks provide easy access to the power pack from both sides, while a tag-out engine isolator improves safety during maintenance. The hydraulically folding hopper, which can be locked from ground level, facilitates quick and efficient setup and teardown.
